2.0mm pin connector Double Row Flat SMT

dgyzconn’s 2.0mm Pin Connector Double Row Flat SMT is developed to solve the challenges of high-density wiring and signal transmission in compact electronic devices. As an innovative product in the 2.0mm Pitch Pin Header series, its standard 2.0mm pitch double-row flat structure perfectly meets the ultra-thin space layout requirements of PCB boards, becoming an industry-preferred choice in the Pin Header Double Row 2.0mm pitch category for its unique flat design and stable performance.



This connector features high-purity copper alloy pins with a diameter of 0.50.5 (**Pin diameter 0.50.5**), tin-plated surfaces (2.0mm Tin-plated pin header), paired with high-temperature-resistant LCP materials (2.0mm pitch LCP material), and a single-layer plastic structure (2.0mm pitch single layer plastic pin headers). Installed via SMT technology (2.0mm SMT Pin Header), it can stably carry 4A current in environments ranging from -40°C to +105°C, with a contact resistance as low as 15mΩ. The flat design significantly reduces the overall height to only 1.5mm, effectively saving space. The double-row layout supports parallel transmission of up to 20PIN signals, meeting high-speed data interaction needs. The design without locating posts (2.0mm pitch pin header without locating posts) provides flexible wiring adjustment space. Certified by IATF16949, ISO9001, and RoHS-compliant, it is widely used in smartwatches, ultra-thin laptops, etc., offering efficient solutions for precise electronic connections.

Item	Description
Application	Primarily used for internal device connections; not suitable for external connectivity.
	Applicable for electronics, industrial computers, telecom systems, aftermarket components.
Soldering Type	SMT / Straight / Right Angle / J Type / U Type
Plastic Row Options	Single Row, Dual Row
Rated Current	2A per pin
Operating Temperature	-40°C to +105°C
Terminal Material	C2680; C5191
Insulator Material	LCP (UL94V-0), Black
Processing Temperature Range	230°C to +260°C
Contact Resistance	Max 20mΩ
Contact Plating	Gold Flash plating
	Nickel underlayer ≥50μ"
Number of Contacts	6–80 PINs
Certifications	ISO9001, ISO14000
RoHS Compliance	Yes
Material Options	PBT, PA46, PA6T, PA9T, LCP
Packaging	Standard: plastic tray + carton; customizable upon request
Service	ODM and OEM support; color customization available
