The 5.08mm Pitch Triple Row Pin Header, configured for 180° straight-through mounting, is a robust and versatile Pin Header Connector engineered for high-power, high-density applications. This unique version includes selective pin removal, allowing customized electrical paths and signal integrity optimization.

With its triple row design, this Pin Header 5.08mm Pitch product supports complex routing needs in power management modules, industrial automation controllers, and communication hubs. It’s particularly effective in applications where space is at a premium but signal diversity and current demands are high.

The 5.08mm pitch offers wide spacing for better insulation and heat dissipation, making this product suitable for high-current scenarios. Each pin can handle up to 7A, thanks to the use of premium copper alloy terminals (C2680/C5191) and low contact resistance (maximum 20mΩ). The tin-plated contact surface ensures corrosion resistance and long-term electrical reliability under demanding environments.

Item	Description
Application	Primarily used for internal device connections, not for external connectors
Suitable Industries	Electronics, Industrial PCs, Communication Systems, Aftermarket Components
Mounting Type	SMT / Straight / Right Angle / J-Type / U-Type
Rows of Plastic	Single Row / Double Row
Rated Current	7A per pin
Operating Temperature	-40°C to +105°C
Terminal Material	C2680; C5191
Insulator Material	LCP (UL94V-0), Black
Processing Temperature	230°C to 260°C
Contact Resistance	Max 20mΩ
Contact Plating	Tin Plating: 80–120μ"
Base Nickel Layer	≥50μ"
Number of Contacts	6–20 PINs
Certifications	IATF16949, ISO9001, ISO14000
RoHS Compliance	Yes
Materials	LCP
Packaging	Standard: Plastic Tray + Carton (customizable on request)
Service Type	ODM & OEM available; color customization supported

Our engineering team works closely with clients across industrial, automotive, and communication sectors to develop Pin Header Double or Double Sided Pin Header solutions that meet strict mechanical, thermal, and electrical requirements. We also support female to female pin header integration for complete interconnect solutions.
