180 degree Box Header black

dgyzconn’s 180 degree Box Header black stands as an outstanding choice for internal device connections, meticulously crafted for electronics, industrial computers, communication systems, and after-sales parts. As a classic in the Box Header series, its unique 180-degree design with a double-row structure enables efficient and stable connections in tight spaces, perfectly adapting to various complex circuit layout requirements. With support for multiple soldering types like SMT, angled, and right-angle, it easily meets the installation needs of any Header Connector.



Featuring high-quality C2680 and C5191 terminals paired with black LCP (UL94V - 0) insulators, this connector operates stably from - 40°C to + 105°C. The 3A/pin rated current ensures smooth operation of high-load circuits. The Gold Flash plating, combined with a ≥50u" nickel base layer, keeps the contact resistance at a maximum of 20mΩ, guaranteeing lossless signal transmission. With 6 - 64 PIN options, it suits the precise connection needs of different devices and is highly compatible with specifications such as 2.54mm 180 degree Box Header and black Box Header 2.54mm. Certified by IATF16949, ISO9001, ISO14000, and RoHS-compliant, it comes in standard plastic tray + carton packaging. Offering ODM and OEM customization services with flexible color choices, it provides a one-stop high-quality solution for internal device connections.
