Double Row Female Header With Inner Pillar
Double Row Female Header With Inner Pillar
Double Row Female Header With Inner Pillar
Double Row Female Header With Inner Pillar
Double Row Female Header With Inner Pillar

Double Row Female Header With Inner Pillar

Get Latest Price
Min. Order:1
Product Attributes

Model No.052835

Packaging & Delivery

The file is encrypted. Please fill in the following information to continue accessing it

Product Description
dgyzconn’s Double Row Female Header With Inner Pillar is an innovative product in the field of internal device connections, specially designed for electronics, industrial computers, and communication systems. As a star product in the Female Header series, its unique inner pillar design combined with a double-row structure not only significantly enhances the connector's stability and durability but also ensures stable signal transmission in complex environments, making it an ideal choice for high-density wiring scenarios.

This connector supports various soldering types, including SMT, straight, right-angle, J-type, and U-type, perfectly adapting to both automated patching production and manual assembly, especially suitable for the special installation requirements of Right Angle Female Header. With high-quality C2680 and C5191 terminals paired with black LCP (UL94V - 0) insulators, it operates stably with a 3A/pin rated current in harsh environments ranging from -40°C to +105°C. The Gold Flash plating, combined with a ≥50u" nickel base layer, strictly limits the contact resistance to a maximum of 20mΩ, effectively reducing signal loss. The flexible 6 - 80 PIN configuration meets the requirements of different devices and is highly compatible with Male And Female Header Pins and Female Header Pins. Certified by IATF16949, ISO9001, ISO14000 and RoHS-compliant, it comes in standard plastic tray + carton packaging. Offering flexible ODM and OEM customization services with adjustable colors, it satisfies diverse market demands.
Attributes Details
Application Mainly for internal device connections; suitable for electronics, industrial computers, communication systems, after-sales parts, etc.
Soldering Type SMT / Straight / Right-angle / J-type / U-type
Plastic Rows Single-row, Double-row
Rated Current 3A/pin
Operating Temperature -40°C to +105°C
Terminal Material C2680; C5191
Insulator Material LCP (UL94V-0), Black
Processing Temperature Range 230°C to +260°C
Contact Resistance Maximum 20mΩ
Contact Plating Gold Flash; Nickel layer on base plate ≥50u"
Pin Count 6 - 80 PIN
Certifications IATF16949, ISO9001, ISO14000
RoHS Compliance Yes
Materials PBT, PA46, PA6T, PA9T, LCP
Packaging Details Standard packaging: plastic tray + carton; customizable according to requirements
Service Types ODM and OEM services available; color can be customized flexibly
