2.54mm Dual Row Triple SMT Pin Header

The 2.54mm Dual Row Triple Plastic SMT Pin Header is designed for high-density board-to-board or board-to-cable applications. With its SMT (Surface Mount Technology) termination and three-layer plastic support structure, this Pin Header 2.54mm Pitch model offers enhanced mechanical stability and precision alignment during reflow soldering. Its compact footprint makes it ideal for embedded systems, communication devices, and consumer electronics. The use of high-temperature black LCP insulation ensures compatibility with standard SMT assembly lines.



As a professional Pin Header Connector manufacturer, dgyzconn delivers custom PCB connectivity solutions with a focus on structural integrity and compliance. Our Pcb Board Connector products can be tailored by height, plating, and packaging. Certified under ISO9001 and IATF16949, we guarantee high-quality, RoHS-compliant manufacturing for global customers seeking reliable 2.54 Mm Pin Header and Double Sided Pin Header solutions.



Item	Description
Application	Primarily used for internal device connections
Suitable Industries	Electronics, Industrial PCs, Communication Systems, Aftermarket Components
Mounting Type	SMT / Straight / Right Angle / J-Type / U-Type
Rows of Plastic	Single Row / Double Row
Rated Current	3A per pin
Operating Temperature	-40°C to +105°C
Terminal Material	C2680; C5191
Insulator Material	LCP (UL94V-0), Black
Processing Temperature	230°C to 260°C
Contact Resistance	Max 20mΩ
Contact Plating	Gold Flash / Tin Plating
Base Nickel Layer	≥50μ"
Number of Contacts	6–80 PINs
Certifications	IATF16949, ISO9001, ISO14000
RoHS Compliance	Yes
Materials	PBT, PA46, PA6T, PA9T, LCP
Packaging	Standard: Plastic Tray + Carton (customizable on request)
Service Type	ODM & OEM services available; flexible color customization supported
