3.5mm pitch connector double row 90 degree

dgyzconn’s 3.5mm pitch connector double row 90 degree is a high-performance solution customized for three-dimensional wiring and anti-interference requirements in industrial equipment. As a core model in the 3.5 Spacing connector series, its standard 3.5mm pitch double-row right-angle structure precisely adapts to high-density connection scenarios in the vertical space of PCB boards, standing out in the 3.5 Spacing connector double row category for excellent signal isolation and mechanical strength.



Featuring thickened copper alloy pins with tin-plated surfaces, this connector meets the stable connection requirements of Female Connector Head, with a rated current of 6A per pin, operating stably in -40°C to +105°C environments and achieving a contact resistance as low as 15mΩ. The 90-degree right-angle technology (derived from 3.5 Spacing connector 180 degree process logic), paired with a high-temperature-resistant LCP material shell, ensures secure soldering via SMT technology. The double-layer insulation structure (implied in the double-row design) effectively reduces crosstalk. The double-row layout supports parallel transmission of up to 36PIN signals, with a 4.5mm plastic height and locating posts design to ensure precise installation. Compliant with RoHS standards and ISO9001 certified, it is widely used in industrial automation equipment, communication base stations, etc., providing reliable right-angle interconnection support for complex circuits.
