2.54mm Triple Row 90° Pin Header

The 2.54mm Triple Row 90° Pin Header provides an efficient high-density connection solution for PCB assemblies requiring multiple rows of pins within a limited footprint. With a 90-degree right-angle configuration, this pin header facilitates horizontal board connections that are commonly used in industrial computers, telecommunications, and automation systems. Its triple-row layout significantly increases pin count while maintaining reliable electrical contact and mechanical stability. Constructed from premium copper alloy contacts and UL94V-0 rated plastic housing, this connector maintains high performance under harsh operating conditions and repeated thermal cycles.



dgyzconn offers full customization for Pin Header 2.54mm Pitch products, including triple row variants like this one. We provide flexible design modifications, plating options such as gold flash or tin, and various packaging formats tailored to production scale. Our professional quality control and certifications like ISO14000 ensure compliance with global standards. Customers benefit from our OEM and ODM capabilities, making dgyzconn a trusted partner in delivering durable and precise Pin Header Connectors and Pcb Board Connectors worldwide.

Item	Description
Application	Primarily used for internal device connections
Suitable Industries	Electronics, Industrial PCs, Communication Systems, Aftermarket Components
Mounting Type	SMT / Straight / Right Angle / J-Type / U-Type
Rows of Plastic	Single Row / Double Row
Rated Current	3A per pin
Operating Temperature	-40°C to +105°C
Terminal Material	C2680; C5191
Insulator Material	LCP (UL94V-0), Black
Processing Temperature	230°C to 260°C
Contact Resistance	Max 20mΩ
Contact Plating	Gold Flash / Tin Plating
Base Nickel Layer	≥50μ"
Number of Contacts	6–80 PINs
Certifications	IATF16949, ISO9001, ISO14000
RoHS Compliance	Yes
Materials	PBT, PA46, PA6T, PA9T, LCP
Packaging	Standard: Plastic Tray + Carton (customizable on request)
Service Type	ODM & OEM services available; flexible color customization supported
