2.54mm Triple Row 180 Degree Pin Header

The 2.54mm Triple Row 180° Pin Header is designed for applications that demand high pin density with straight vertical mounting. Featuring three rows of pins spaced at 2.54 mm, this connector enables compact and reliable board-to-board interfaces, commonly applied in embedded systems, communication equipment, and industrial electronics. Its through-hole pins ensure strong mechanical retention on PCBs, while the LCP housing withstands high temperatures and mechanical stress during SMT soldering. The contact surfaces plated with gold flash provide low contact resistance and excellent durability.



dgyzconn provides comprehensive customization services for the 2.54 Mm Pin Header family, including triple row, 180° configurations. Our engineering team supports modifications in pin number, plating type, and packaging to meet your specific project demands. We uphold strict quality standards certified by IATF16949 and ISO9001, offering dependable Pin Header Connector solutions that integrate seamlessly into your production line. Partner with dgyzconn for tailored Pin Connector products backed by professional service and competitive pricing.



Item	Description
Application	Primarily used for internal device connections
Suitable Industries	Electronics, Industrial PCs, Communication Systems, Aftermarket Components
Mounting Type	SMT / Straight / Right Angle / J-Type / U-Type
Rows of Plastic	Single Row / Double Row
Rated Current	3A per pin
Operating Temperature	-40°C to +105°C
Terminal Material	C2680; C5191
Insulator Material	LCP (UL94V-0), Black
Processing Temperature	230°C to 260°C
Contact Resistance	Max 20mΩ
Contact Plating	Gold Flash / Tin Plating
Base Nickel Layer	≥50μ"
Number of Contacts	6–80 PINs
Certifications	IATF16949, ISO9001, ISO14000
RoHS Compliance	Yes
Materials	PBT, PA46, PA6T, PA9T, LCP
Packaging	Standard: Plastic Tray + Carton (customizable on request)
Service Type	ODM & OEM services available; flexible color customization supported
